Technical data
| Manufacturer | Balluff |
|---|---|
| Manufacturer part number | BES M08EG1-PSC15A-S04G-W |
| Condition | Used |
| Model family | BES02YT |
| Model | Inductive sensor |
| Product type | Sensors and Actuators |
Description
Dimension: Ø 8 x 57 mm
Design: M8x1
Mounting: flush
Range: 1.5 mm
Switching output: PNP normally open (NO)
Switching frequency: 2000 Hz
Housing material: stainless steel (1.4301), coated, PTFE
Active face, material: PBT/PTFE
Connection: connector, M12x1-Stecker, 4-pin
Operating voltage (Ub): 10...30 VDC
Ambient temperature: -25...70 °C
Magnetic field immunity: magnetic field resistant (AC/DC)
Protection class: IP67
Approval/Conformity: CE, WEEE
Additional features: factor 1, weld-resistant
